KM Stainless Steel Steam Wand for DeLonghi Machines
Kompatibel mit DeLonghi Dedica EC685, EC680 sowie modellabhängig mit DeLonghi Magnifica S ECAM.
Product Details:
- Precise Steam: Calm, directed steam jet instead of uncontrolled spray nozzle.
- Better Texturing: Suitable for fine-pored microfoam.
- More Control: Significantly better controllable angle and range of motion when frothing.
- Upgrade Instead of Replacement: Get more out of existing single-boiler machines without replacing the machine.
Technical Details:
| Total length of wand: | approx. 8.2 cm |
| Nozzle type: | Single-hole nozzle, designed for constant flow rate |
| Material: | Stainless steel |
| Assembly: | Tool-free installation possible |
| Scope of delivery: | 1x stainless steel steam wand and 4x seals |
| Cleaning: | dishwasher safe, daily cleaning with flush and microfiber cloth is sufficient |
Compatible Machines:
- DeLonghi Dedica EC 680
- DeLonghi Dedica EC 685
- DeLonghi Magnifica S ECAM22.110.SB - Fully Automatic
Other machines with identical connection and steam assembly may be compatible.
Important Notes:
- The wand improves steam volume and controllability, but does not turn a single-boiler machine into a commercial-grade machine.
- For reproducible results, we recommend a suitable Milchkanne.
- Flush briefly before frothing to remove condensation from the wand.
Steam Wand Assembly Instructions
More control. Better microstructure. Finally froth milk properly with the Dedica. Assembly takes less than 5 minutes – if you know how.
Short video for assembly – step by step.
Turn off the machine, pull the power plug, and let it cool completely. Release all steam pressure.
Scope of Delivery
- 1× Stainless Steel Steam Wand
- 1× Transparent Seal Ring (for assembly)
- Additional Seal Rings as Spares
Step 1 – Remove Original Steam Wand
- Push the original steam wand upward.
- At the same time, turn counterclockwise.
- Pull downward to remove.
- Completely remove the black rubber outlet.
Step 2 – Insert Seal Ring
Slide the transparent seal ring onto the plastic outlet.
The additional seal rings are spare parts only.
Step 3 – Install New Steam Wand
Place the new steam wand straight and apply gentle upward pressure while sliding it on. Push it up to the upper stop.
It must sit fully at the top.
Step 4 – Secure
Turn clockwise until the plastic pin sits completely in the corner.
Tighten by hand – do not use any tools.
Step 5 – Function Check
- Turn on the machine
- Brief steam release (without milk)
- Check if steam escapes from the sides
Care & Tips from Us
- Clean immediately with a damp cloth after each use
- Let steam run briefly to blow out milk residue
- Check the seal regularly
Our Tip: Let steam run for 5–10 seconds before frothing milk for the first time. This stabilizes the steam and ensures better microstructure.
How Do I Froth Correctly?
With this steam wand upgrade, real, fine-pored microfoam (latte art quality) is finally possible. Unlike the original "Panarello," you now have full control over the two crucial phases:
- Draw Phase: This is where you introduce air into the milk to create volume.
- Roll Phase: This is where you whirl the foam so it becomes silky and fine-pored.
A detailed step-by-step guide including video can be found in our magazine article:
Go to the guide: Latte Art at Home
Want to Master the DeLonghi Dedica Completely?
In our special online course, we not only explain frothing in detail, but also show you how to get everything out of your machine: from the perfect espresso to a delicious cappuccino.
Why We Sell This Steam Wand
Many small espresso machines are surprisingly powerful with espresso but lose significant quality with steam. Original steam wands often produce unsteady steam, unreliable whirlpool formation, and coarse foam.
In our tests, this wand clearly upgraded the Dedica and compatible machines: shorter frothing times, more stable steam, and milk foam that can be poured in a controlled manner. For anyone who wants to meaningfully upgrade their existing machine, this steam wand is a logical step before considering a complete machine replacement.
